PRODUCT PARAMETERS
● Rated voltage：90~265 Vac
● BUS Voltage：310Vdc
● Rated frequency：50/60HZ
● Blade Material：Aluminum
● Motor Type：High Voltage BLDC Motor
● Inverter：3 Phase Pure Sine Wave
| Model | XIF-24 | XIF-30 | XIF-36 | XIF-42 | XIF-48 |
| Input Power | 80 W | 120 W | 150 W | 200 W | 300 |
| Blade Diameter | 24 Inches | 30 Inches | 36 Inches | 42 Inches | 48 Inches |
| Number of blades | 3 | 4 | |||
| RPM Max | 1350 | 825 | 500 | ||
| Current | 0.36 | 0.55 | 0.68 | 0.91 | 1.36 |
FEATURES
● Speed Control：100~Max linear
● Rotation：CW/CCW
● Explosion Proof：Optional
● Smart Inside：Nature wind stimulator/Temperature Synchronize
● Drive Type：Direct
● Display：Real time RPM, Power consumtion, Error code
